Laser per lesioni vascolari LASEVIA

per ringiovanimento vulvo-vaginaleper lipolisiper biostimolazione ortopedica

Présentation
LASEVIA is a multi-wavelength diode laser platform uniting semiconductor sources (examples: 1940 / 1470 / 980 / 635 / 450 nm) in a single portable console. Designed for clinic use, the platform supports aesthetic and surgical indications across eight clinical specialties with up to 30 W+ peak output. The system features an 11.6-inch Android touchscreen, Class 4 safety hardware (emergency stop and mechanical shutter) and an SMA905 universal fiber port.

Wavelength architecture & configurations
Four/five available wavelengths (configuration-dependent). Each diode is matched to specific chromophores (water, haemoglobin, lipid, melanin). Select a single wavelength or combine them per protocol.

Factory configurations (examples)
Configuration A:
1940 nm — 10 W · 1470 nm — 15 W · 980 nm — 20 W · 635 nm — 500 mW · fiber core 200 µm

Configuration B:
1470 nm — 15 W · 980 nm — 30 W · 450 nm — 8 W · 635 nm — 2 W · fiber cores 200 / 400 µm

Clinical specialties (eight)

• Endolifting (deep 1940 nm fractional fiber remodeling — non-surgical lifting for face, neck, body)
• Lipolysis (ring-light fiber emulsifies adipose via micro-cannulas for mini-invasive body contouring)
• Spider vein & Vascular (transdermal and endovenous coagulation; 635 nm surface mode)
• Therapy · HILT Class IV (deep-tissue photobiomodulation for pain, inflammation and tissue repair)
• LVR (non-ablative 635 nm vaginal rejuvenation / intimate health)
• Proctology (fiber-delivered coagulation for haemorrhoids and fistulas)
• EVLT (endovenous laser ablation using water-absorbed wavelengths for vein sealing)
• ENT (450 nm blue for minimally invasive soft-tissue surgery)

Delivery, handpieces & fibers

• Universal SMA905 fiber port accepts contact fibers (200 / 400 / 600 / 1000 µm) and non-contact tips
• Handpiece sets: Basic Handpiece Set (endolifting · lipolysis), Advanced Liposuction Set, SUPERSCAN Focus Set (spider vein · fractional), LVR Handpiece Set, PM5 Therapy Set, Disposable LVR and Disposable Surgical sets
• Fiber types: High-Power Fiber (SMA905), Bare Fiber (direct contact), Polyimide Fiber (polyimide-coated), Radial Fiber (360° emission), Hemorrhoid Fiber (600 µm typical; cylindrical/conical emission)
• Accessories: Laser safety goggles, foot switch, fiber cutter, fiber stripper, connector cleaner

Emission modes & performance

• Emission modes: CW · single pulse · repeat pulse
• Pulse width range: 25 µs – 10 s
• Repetition rate: 0.05 Hz – 50 kHz
• Peak output: up to 30 W+

Interface & device features

• 11.6″ Android smart touchscreen: touch presets, real-time energy readouts and one-tap protocol recall; glove-friendly
• Emergency laser stop (mushroom switch) and mechanical safety shutter
• Portable console: approx. 15 kg with single-handle carry frame
• Multi-mode emission tailored per indication; one console supports both aesthetic and surgical workflows

Notes on clinical use

• Wavelength selection is indication-dependent; wavelengths can be independently switched
• Some clinical protocols use combinations of wavelengths for optimized chromophore targeting
• Specifications and available configurations are market-dependent and subject to change

caractéristiques / spécifications techniques

• Laser type: Multi-wavelength semiconductor (diode) laser platform
• Wavelengths: 450 / 635 / 980 / 1470 / 1940 nm — configuration dependent
• Maximum output: Up to 30 W+
• Configuration A: 1940 nm 10 W · 1470 nm 15 W · 980 nm 20 W · 635 nm 500 mW · fiber 200 µm
• Configuration B: 1470 nm 15 W · 980 nm 30 W · 450 nm 8 W · 635 nm 2 W · fiber 200 / 400 µm
• Emission modes: CW · single pulse · repeat pulse
• Pulse width: 25 µs – 10 s
• Repetition rate: 0.05 Hz – 50 kHz
• Delivery system: SMA905 fiber interface · contact fibers 200 / 400 / 600 / 1000 µm · non-contact tips
• Interface: 11.6″ Android smart touchscreen
• Safety: Emergency laser stop · mechanical safety shutter · Class 4
• Power supply: 100 – 240 V, 50 – 60 Hz, 350 VA
• Weight: 15 kg (portable console)
• Certification / quality: CE · MDSAP · ISO 13485 · FDA-cleared therapeutic laser technology
