Laser per fotostimolazione veterinaria per equini GBOX PLUS

per cavallitrasportabileper riabilitazione

Overview
Class 4 Laser Therapy designed for equine athletes. Non-invasive laser treatment that penetrates deep into tissues to accelerate healing, reduce inflammation and support faster recovery for horses.

Ideal for

• Post-race recovery
• Tendon injuries
• Arthritis
• Pain management
• Preventive care

Key benefits

• Non-invasive & painless — avoids the risks associated with injections or surgery
• Accelerates healing & enhances performance — reduces inflammation and promotes tissue repair
• Reduces pain & improves flexibility — helps horses regain competitive condition faster
• Short treatment time, fast results — typical sessions 5–15 minutes

Product highlights

• High-power Class 4 laser technology
• Multi-wavelength design for deep tissue penetration
• Smart handpiece for easy operation
• Portable design suitable for racehorse facilities, veterinary clinics and equine care centers

Features (selected)

• Wavelengths: multi-wavelength options (1064nm, 980nm, 915nm, 810nm, 635nm) — combinations and independent control
• Operational modes: Continuous Wave (CW) and Intense Superpulse (ISP) mode with variable duty cycle for deeper stimulation while reducing surface heating
• Power options: CW 40W + 2000mW (635nm); ISP peak 55W + 2000mW (635nm)
• Battery management: changeable battery; full power ~1 hour; low power up to ~4 hours; designed for both portable and stationary use
• Software: HD touch-screen (Android) with customizable protocols and patient history data storage
• Handpiece optics: multiple optics available to target different tissue depths and treatment areas

Case studies / Real success stories

• Injured racehorse reported ~80% tissue healing within 3 weeks of laser therapy (case example)
• Equestrian team reported reduced recovery time by ~40% using Class 4 laser therapy (case example)

Caractéristiques / spécifications techniques

• Frequencies: 0.2 to 20,000 Hz & ISP
• Diode: High powered solid-state diode module
• Weight: 4.2 kg without battery, 4.8 kg with battery (handpiece dimensions: 265(W)*270(L)*120(H) mm shown for an element)
• Battery: Full power ~1 hour; low power up to ~4 hours; changeable battery; provisions for 7 day (stationary) use
• Technology platform: 10.1 inch HD touch screen, Android platform, Wi‑Fi enabled for software updates
• Hand Piece Optics: 30 mm open zoom lens; 30 mm curved contact lens; 10 mm curved contact lens; 5 mm TMJ lens; 30 mm 360° rolling large massage ball lens
• Customizable Protocols: Yes (save personalized treatment protocols for each patient)
• Unlimited Patient History Data: Yes
• Laser Cable: fibers of 400 μm and 600 μm with SMA905 connector
• Pain Scale: Yes
• BMI Tone Selection: Yes
• Skin Tone Selection: Yes
• Wavelength Combinations: 1064 nm + 980 nm + 915 nm + 810 nm + 635 nm (any combinations + independent control)
• Intense Superpulse Peak (ISP): 55W + 2000 mW (635 nm)
• Continuous Wave Power (CW): 40W + 2000 mW (635 nm)
• Folding Screen: Yes
• Shoulder Sling / Portable: Yes
• Clinical Support: Yes
