Analizzatore di VES automatico BK-ESR series

elettricoper diagnosi clinicarandom access

Introduction: ESR testing has important guiding significance for many clinical diseases, but the traditional standard Westergren method has complicated operation, low work efficiency and large cross-contamination. Automatic ESR analyzer uses advanced infrared light color difference interpretation technology to automatically scan the whole process of red blood cell sedimentation within 30 minutes for the sample of the vacuum blood collection tube and, referring to the Westergren method and measured standard curve, obtains accurate results.

Application: Applicable to hospital inspection departments, medical laboratories, research institutes, universities, disease control centers, etc.

Features:

• 7.0-inch color touch screen, real-time display of sample status.
• Randomly insert sample positions for testing at any time.
• Built-in thermal printer, can print dynamic ESR curve.
• Infrared optical detection and precise measurement; results automatically complete temperature compensation, pressure volume compensation, and ESR equation K value.
• With USB, Type-C interface and host computer supporting software; supports uploading test results to LIS/HIS system.
• Power-off protection function, automatic saving of test results, sample abnormality alarm and recording function.
• Adjustable base height with a leveling level to ensure accurate detection.

Technical Parameter:
Model: BK-ESR20pro | BK-ESR40pro
Application: Erythrocyte sedimentation rate analysis
Measurement Method: Infrared detection
Analysis Result: Westergren ESR value (mm/hour)
Throughput: Maximum 40 tests/hour | Maximum 80 tests/hour
Analysis Channels: 20 (load up to 20 samples for analysis at the same time) | 40 (load up to 40 samples for analysis at the same time)
Loading Type: Load samples at any time, measure at any time
Analysis Time: 30 minutes or 60 minutes selectable
Sampling Interval: 3 min
Measurement Range: 0~150 mm/h
Temperature Compensation: The result is automatically corrected to the result at 18°C
Result Resolution: 1mm/1h and 1mm/2h
Blood Level Range: 46mm~64mm
HCT Range: 0.2~1.0
Repeatability: 0~10mm/h, SD≤1.5mm/h; >10mm/h, CV≤8%
Channel Consistency: 0~10mm/h, SD≤1.5mm/h; >10mm/h, CV≤8%
Reading Accuracy: ±0.1mm
Display: 7-inch color LCD touch screen
Communication Interface: Type-C, USB interface
Printer: Built-in thermal printer
Power Supply: AC110~220V, 50/60Hz
External Size (W*D*H): 284*355*208mm
Net Weight: 5.6kg | 6.3kg
Package Size (W*D*H): 339*544*249mm
Gross Weight: 8.7kg | 9.4kg

Caractéristiques / spécifications techniques:

• Model/Series: BK-ESR20pro; BK-ESR40pro (BK-ESR series)
• Intended use: Erythrocyte sedimentation rate analysis for clinical labs and medical institutions
• Measurement method: Infrared optical detection
• Throughput: 40 tests/hour (BK-ESR20pro) or 80 tests/hour (BK-ESR40pro)
• Channels: 20 (BK-ESR20pro) or 40 (BK-ESR40pro)
• Analysis time options: 30 min or 60 min
• Sampling interval: 3 minutes
• Measurement range: 0–150 mm/h
• Temperature compensation: Automatic correction to result at 18°C
• Result resolution: 1 mm/1h and 1 mm/2h
• Blood level range: 46–64 mm
• HCT range: 0.2–1.0
• Repeatability / Channel consistency: 0–10 mm/h SD ≤ 1.5 mm/h; >10 mm/h CV ≤ 8%
• Reading accuracy: ±0.1 mm
• Display: 7-inch color LCD touch screen
• Interfaces: Type-C, USB; supports LIS/HIS upload
• Printer: Built-in thermal printer
• Power supply: AC 110–220 V, 50/60 Hz
• Dimensions (W*D*H): 284*355*208 mm
• Net weight: 5.6 kg (BK-ESR20pro) / 6.3 kg (BK-ESR40pro)
• Package size: 339*544*249 mm
• Gross weight: 8.7 kg (BK-ESR20pro) / 9.4 kg (BK-ESR40pro)
